This series of electric pneumatic solenoid valves is optimized for seamless integration with double-acting and single-acting pneumatic cylinders, providing stable switching performance even in continuous high-cycle operation. Designed for industrial equipment manufacturers, automation integrators, and engineering contractors, our 4V series valves offer unmatched durability and flexibility to meet diverse pneumatic system demands.
Precision Directional Control: The valve core adopts precision grinding process, achieving ±0.01mm repeatability for consistent airflow switching and zero leakage in long-term operation.
Wide Operating Parameter Range: Supports 0.15-1.0MPa working pressure, with a temperature tolerance of -20℃ to 70℃, adapting to harsh industrial environments.
Low Power Consumption & High Efficiency: High-purity copper coil design reduces energy loss, while maintaining fast response speed for high-frequency operation up to 120 cycles per minute.
Modular & Flexible Installation: Compatible with dedicated manifold mounting bases, supporting multi-station combined installation to save space in control cabinets.
Integrated Sensor Compatibility: Built-in magnetic ring structure supports matching magnetic switches for real-time valve position monitoring in automated systems.
Parameter | Specification Details |
Series Model | 4V100, 4V200, 4V300, 4V400 |
Operating Medium | Filtered compressed air (40μm+ filtration) |
Working Pressure Range | 0.15-1.0MPa |
Proof Pressure | 1.5MPa |
Ambient & Fluid Temperature | -20℃ to 70℃ |
Operation Frequency | Max. 120 cycles per minute |
Lubrication | Not required |
Coil Voltage Options | DC12V, DC24V, AC110V, AC220V |
Port Size | M5×0.8, Rc1/8, Rc1/4, Rc3/8, Rc1/2 |
The 4V Series industrial pneumatic solenoid valve features a rugged, corrosion-resistant body made of high-strength die-cast aluminum alloy, with a precision-ground stainless steel valve core for wear resistance and smooth movement. Sealing components use high-performance NBR nitrile rubber, delivering excellent oil resistance, aging resistance, and zero air leakage over 1 million switching cycles. The coil is encapsulated with flame-retardant and waterproof material, reaching IP65 protection level for dust and splash resistance in factory floor environments.
This pneumatic solenoid control valve is widely used across core industrial sectors, including automated assembly lines, packaging machinery, food and beverage processing equipment, automotive manufacturing, textile machinery, printing presses, material handling systems, and robotic automation cells. It is the preferred control component for any pneumatic system requiring reliable directional airflow control.
All our 4V series pneumatic valves undergo full functional and pressure testing before delivery, complying with international ISO pneumatic component standards. We offer comprehensive custom solutions, including special voltage configurations, explosion-proof models, non-standard manifold assemblies, and custom port sizes. Our dedicated technical team provides pre-sales selection guidance and after-sales support, with flexible lead times for both standard and custom orders.
Can the 4V series pneumatic solenoid control valve be used in high-humidity environments?
Yes, the valve features an IP65 waterproof coil and corrosion-resistant body, making it suitable for high-humidity and dust-heavy industrial environments.
Is manifold mounting available for this valve series?
Absolutely, we offer dedicated manifold bases for all 4V series models, supporting 2-20 station combined installations for centralized pneumatic control systems.
What is the service life of the valve?
Under standard operating conditions, the valve delivers a service life of over 5 million switching cycles, with replaceable sealing components for extended usability.
